I2C 20X4 Green-Yellow LCD Display Module

R 156.00

This I2C 20X4 LCD Display Module is a is a 4 line 20 character LCD module that can display alphanumerical characters – with space for up to 8 extra characters or symbols. The module can be controlled via 6 digital or analog inputs and can be operated from either a 4-bit or an 8-bit microprocessor.

Quantity

Stock Available
41 Items

Overview:

This I2C 20X4 LCD Display Module is a is a 4 line 20 character LCD module that can display alphanumerical characters – with space for up to 8 extra characters or symbols. The module can be controlled via 6 digital or analog inputs and can be operated from either a 4-bit or an 8-bit microprocessor.

Specification:

• Operating Voltage – 4-5V DC
• Controller – HD44780
• MPU Interface – 4-bit and 8-bit
• Display RAM Capacity – 80 x 8-bit Characters
• Display: yellow green
• Interface: I2C
• I2C address: 0x27 or 0x3F random delivery
• Pin definition: GND, VCC, SDA, SCL
• Contrast adjust: potentiometer
• Display format: 20 Characters x 4 lines
• Adjustable backlight
• The module can be easily interfaced with a MCU
• Fully assembled and tested serial LCD 20 x 4 module
• The module is a low-power consumption character LCD module with a built-in controller
• Size: 9.8 x 6 x 1.2mm

Resources:

• User Manual
