micro:bit Mini Servo Shield with Battery holder

R 190.00

The Micro bit Mini Servo Shield with Battery holder is fully compatible with micro bit control board. It comes with SK6812-P4 RGB LED and 4 3pin ports with 2.54mm pitch.

Note: The BBC micro:bit board and Servo's are NOT included. This unit is NOT manufactured or supplied by the BBC micro:bit but compatible with the BBC micro:bit

Quantity

Stock Available
4 Items

Overview:

This shield is fully compatible with micro bit control board. It comes with SK6812-P4 RGB LED and 4 3pin ports with 2.54mm pitch. Fix battery holder with 2M3*6MM flat screws and 2 M3 nuts, place 3 AAA batteries(not included) inside, and install the micro bit control board on the mini servo car shield with 5 M3*6MM screws. When the right DIP switch on the shield is dialled to the ON end, the battery box supplies power, when dialled to the OFF side, the power can’t be provided. When the left DIP switch is dialled to RGB end, the micro: bit control board can control the color of 5 SK6812-P4 RGB LEDs by code, moreover, the 3pins port at the pxl-bxt can connect SK6812-P4 RGB LED modules and control their colors;when set to SERVO end, micro:bit can regulate the angles of 3 external servos connected to 3pin ports of SERVO1 SERVO2 SERVO.

Specification:

• Working voltage: DC 3.3-5V
• Working current: 60mA
• Maximum power: 300mA
• Working temperature: -25 ℃ --65 ℃
• Size: 58 * 56 * 21mm
• Weight: 24g
• Environmental attributes: ROHS

Resources

https://wiki.keyestudio.com/KS0493_Keyestudio_Micro_bit_Shield_For_Mini_Servo_Car
